VONN Lighting

RUBIK 5 Light LED Fixed Recessed Downlight w/Trim VMDL000605A012WH, White

SKU: VMDL000605A012WH

$132.97 $189.95

60 In Stock.

QUICK SHIP!  Ship In 24-48 Hours

5 Lights LED Fixed Recessed Downlight w/Trim VMDL000605A012WH, Stock Item Beam Angle 34, White

Installation Guide Download
Specification Sheets Download
Line Drawing Download
IES Photometric File Download
IES Photometric File (IES) Download

LED Fixed trim downlight, RUBIK Series

• Aluminum body structure available in White finish
• Integrated LED 5-spot fixture, recessed installation
• IC Rated
• DIMENSIONS: 6.5"L x 1.75"W x 2.25"H
• HOLE SIZE: 6.25"L x 1.5"W
• LENS BEAM ANGLE: offered in 4 beam angles 12°, 20° & 48°(special order required), 34°(stock beam angle)
• STOCK BEAM ANGLE: 34°
• DIMMABLE: 0-10V
• CCT: 3000 Kelvin color temperature
• BRIGHTNESS: 783.14 Lumens
• WATTAGE: 12W
• VOLTAGE: 100-277V
• CRI 90
• IP Rate: IP20
• ETL, cETL, Title 20 Compliant, Title 24 Compliant, Prop 65 Compliant, Energy Star Compliant
• 3 Year Limited Warranty

***THE MEASUREMENTS ARE ROUNDED TO THE NEAREST 1/4"***

Installation Guide Download
Specification Sheets Download
Line Drawing Download
IES Photometric File Download
IES Photometric File (IES) Download


UPC / GTIN

850003683829

Color Temperature

3000K

More Ways To Shop

SalePromo

Availability

Stock Item

Style

Modern

Application

Commercial

Product Type

Downlight Recessed

Hole Size (in)

6.25"L x 1.5"W

Dimming

0-10V

Dimmable

Yes

Driver

YG

IP Rate

IP20

CRI

90

Voltage (V)

100-277V

Series

RUBIK

Power (W)

12W

Luminous Flux (delivered) (Lm)

783.14

Materials

Aluminum, Iron, PMMA

Product Height

2 to 3 inches

Product Width

1 to 2 inches

Product Length

6 to 7 inches

Product Dimensions (in)

6.5"L x 1.77"W x 2.16"H

Adjustable

N

Finish

White

Lense Beam Angle

12 20 34 48

Room

BedroomDining RoomFoyerHallwayKitchenLiving Room
